SAME SILVER 100.4 - Page 387

Fig. 10 - Sectional illustrations of spool valves
A - Section through kickout element.
B - Partial section through double acting spool valve with float position.
C - Partial section through double acting spool valve.
88
8
systems
auxiliary systems
387
