Samsung RFV01U-D2A - RRH Interface; RRH Configuration (with Finger Guard)

Confidential
Chapter 1 Before Installation
RFV01U-D2A Installation Manual v2.0 3
Copyright © 2017, All Rights Reserved.
Figure 2. RRH Configuration (with Finger Guard)
RRH Interface
The following figure depicts the physical view of the RRH interfaces.
[Bottom View]
15.49 (393)
[Front View]
[Top View]
[Left View]
[Right View]
[Rear View]
19.73 (501)
10.03 (255)
15.88 (403)
Unit: in. (mm)
