Chapter 2 Installing System
This chapter describes the installation procedures of the RRH.
Installation Procedure
The following figure depicts the overall procedures for installing the RRH.
Figure 4. Procedure to Install the RRH
Make sure that the power switch of the power supply is OFF when installing the
system. Installing the system with the power switch ON may cause system damage
or fatal human injury when connecting or disconnecting the cables.
To prevent the risk of electrical shock, do not wear accessories such as watches
and rings.
Foundation Work
Unpacking and Transporting
Fixing System
Unpacking Items
Bringing in Items
Marking and Drilling (only wall type)
System Levelling
Fixing System
To Next Page
