Samsung RFV01U-D2A - Fixing RRH_2 Sector Pole Type (Side Installation 1); Fixing RRH_2 Sector Pole Type (Side Installation 2); Fixing Wall Type

Confidential
Chapter 2 Installing System
RFV01U-D2A Installation Manual v2.0 38
Copyright © 2017, All Rights Reserved.
Figure 36. Fixing RRH_2 Sector Pole Type (Side Installation 1)
3 Fix RRH-1 in the same way as the RRH-0.
Figure 37. Fixing RRH_2 Sector Pole Type (Side Installation 2)
Fixing Wall Type
Marking and Drilling for Wall Mounting
To mark on a wall, do the following:
1 Make sure you have the following items:
[RRH-0]
[RRH-0]
M10 Hex. Bolt
(washer assembly)
Unit Bracket Hook
Mounting Bracket_Front
Hook Groove
[RRH-0] [RRH-0] [RRH-1]
