Samsung RFV01U-D2A - RRH Arrangement_1 Sector Wall Type Installation (Side Installation)

Confidential
Chapter 2 Installing System
RFV01U-D2A Installation Manual v2.0 15
Copyright © 2017, All Rights Reserved.
Figure 9. RRH Arrangement_1 Sector Wall Type Installation (Side Installation)
Unit: in. (mm)
[Side View]
[Top View]
19.25 (489)
≥ 32 (800)
≥ 12 (300)
≥ 16 (400)
≥ 8 (200)≥ 8 (200)
D: 10.03 (255)
H: 19.73
(
501
)
[RRH Front]
