Chapter 2 Installing System
RFV01U-D2A Installation Manual v2.0 24
Copyright © 2017, All Rights Reserved.
Figure 19. Fixing Unit Bracket_Standard Installation (1)
3
Place a dummy cover to the RRH left and fix it using fasteners.
Figure 20. Fixing Unit Bracket_Standard Installation (2)
4
Place a unit bracket to the RRH rear and fix it using fasteners.
Dummy Cover
M3 Screw
Dummy Cover
M3 Scre
