Confidential
Chapter 2 Installing System
RFV01U-D2A Installation Manual v2.0 19
Copyright © 2017, All Rights Reserved.
RRH Handling
When transporting the RRH, hold the handle at the top of the RRH (No tool is
needed for holding the handle).
Figure 12. RRH Handling
When lifting or putting down the RRH, two or more operators must hold the
handle and the support bracket respectively. The corner of the RRH may be
scratched if one operator holds the handles.
Handle
Handle
Support
Bracke
