Preface
RFV01U-D2A Installation Manual v2.0 ix
Copyright © 2017, All Rights Reserved.
New and Changed Information
This section describes information that has been added/changed since the previous
publication of this manual.
Added antenna gain. (Personal and Product Safety)
Added a safe distance between the base station antenna and people. (Caution
for Installation in Chapter 1)
Revision History
The following table lists all versions of this document.
Document Number Product/Software
Version
Document
Version
Publication
Date
Remarks
2600-00KTG7GAA RFV01U-D2A 1.0 July 2017 -
2600-00KTG7GAA RFV01U-D2A 2.0 July 2017 -
Organization of This Document
Section Title Description
Chapter 1 Before Installation
This chapter introduces an RRH and describes
items that should be understood before
installation.
Chapter 2 Installing System
This chapter describes the procedures to install
the RRH.
Chapter 3 Connecting Cables
This chapter describes the procedures to connect
the cables to the RRH installed.
Chapter 4 Inspect the Installation
This chapter describes the procedures of
inspecting installation status after RRH
installation and cabling is completed.
Appendix A Acronyms
This annex describes the acronyms used in this
manual.
Appendix B Sector Antenna Installation
This annex describes the sector antenna
installation.
Appendix C Clean the Optical Connectors
This annex describes the procedure of cleaning
the optical connector and cleaning tool.
Appendix D Standard Torque
This annex describes the standard torque when
fastening the bolt.
Related Documentation
LTE eNB System Description
