Chapter 1 Before Installation
RFV01U-D2A Installation Manual v2.0 4
Copyright © 2017, All Rights Reserved.
Figure 3. RRH Interface
[Bottom View]
ANT 1
(
Bias-T
)
ANT2
ANT 3
(
Bias-T
)
DC_PWR ANT4
RET
UD
A
L0
L1
[Right View]
Ground Terminal
