Chapter 2 Installing System
RFV01U-D2A Installation Manual v2.0 50
Copyright © 2017, All Rights Reserved.
3
Fix RRH-1 and RRH-2 in the same way as the RRH-0.
Figure 49. Fixing RRH_3 Sector Wall Type (Standard Installation 2)
To fix the RRH_3 sector for pole type (side) installation, do the following:
1
Make sure you have the following items:
Table 18. Parts and Tools for fixing RRH_3 Sector Wall Type (Side Installation)
Category Description
Parts
M10 × 35L Hex. Bolt(washer assembly,
attached to the unit bracket)
1 EA/RRH
Recommended Torque Value M10 Hex. Bolt 217 lbfin (250 kgf·cm)
Working Tools
Torque Wrench (100 to 400 lbf·in)
Torque Wrench Spanner head (apply Hex. Head: 17 mm)
Spanner (17 mm)
Check the location to install the RRH.
Fix the RRH according to the order of [RRH-0 RRH-1 RRH-2].
[RRH-0] [RRH-1]
[RRH-2]
RRH-1RRH-0 RRH-2
To Next Page
