Disassembly (40”)
Disassembly (40”)
1. Remove 12 screws from the rear cover ,disconnect the cable of function PCB as showed left picture and lift up
the rear cover.
2. Remove 2 screws from the bracket and lift up the bracket side.
Screw
Screw
