Internal View (46”)
Internal View (46”)
Panel (46” SPVA)
▶ Use of LCD general LTI460AA01-V01 panel,
SPVA Panel with response speed of 8ms
Main Board
▶ Receives input of PC
analog, AV, S-video, audio
signals from outside, and
outputs video signals to the
panel using the Scaler,
outputting the same signal as
input from outside
SMPS Board
▶Maker: Dongyang E & P
Function Board
▶ Function key and remote control IR signals are transmitted to Main board,
with signal on LED
Network Board
▶ CPU and Video decoder are used
to process video and audio
Sub Power Board
▶ Maker : Dongyang E & P
※ Reassembly procedures are in the reverse order of disassembly procedures.
