Board Connections – SMPS Board (40”)
Board Connections – SMPS Board (40”)
Connect i ng t o AC
s ocket
Connect i ng t o
Mechani cal
s wi t ch
Lamp Connect or
(Connecting to panel
inverter - left side)
Power Connect or 16P
(Connecting to MAIN board)
Power Connect or 5P
(Connecting to MAIN board,
Relation to Lamp control)
Power
GND
Net wor k Connect or
(Connecting to Network Power)
To Next Page
