Introduction (Front)
Introduction (Front)
MENU :
Use this button to open the on-screen menu and exit from the menu screen or
close screen adjustment menu.
Up/Down button :
Moves from one menu item to another vertically or adjusts selected menu values.
Adjust / Volume button :
Moves from one menu item to another horizontally or adjusts selected menu values.
Also adjusts the audio volume.
ENTER : Activates a highlighted menu item.
SOURCE :
Changing the source is allowed only in external devices that are connected to the
monitor at the time. To switch Screen modes:
[PC] -> [BNC] -> [DVI] -> [AV] -> [S-Video] -> [Component] -> [HDMI] -> [MagicNet]
PIP :
Push the PIP button to turn PIP screen On/Off.
More than one PIP couldn't be overlapped on screen as BNC and the component use
the same terminal.
• PC / DVI : AV / S-Video / Component Mode
• BNC: AV / S-Video Mode
• AV / S-Video : PC / BNC / DVI Mode
• Component: PC / DVI Mode
POWER : Use this button to turn the monitor on and off.
LED : Power Indicator shows Power Saving mode by green blinking.
Remote Control Sensor : Aim the remote control towards this spot on the
Monitor.
Viewing the Control Panel
1. MENU 5. SOURCE
2. Navigate button (Up-Down button) 6. PIP
3. Adjust button (Left-Right button) 7. Power button
Volume button 8. Power indicator
4. ENTER 9. Remote Control Sensor
