Chapter 2 Installation Electrical Installation
Branch Feeder Monitor 136_Installation Operation and Manual 13
2.2 Electrical Installation
BFM136 offers maximum flexibility of current connections by using the variety of HACS options and by
wiring any HACS to any current input of the device. The following drawings present applications serviced
by the BFM136.
Before installation ensure that all incoming power sources are shut OFF. Failure to
observe this practice can result in serious or even fatal injury and damage to equipment
Figure 2-5a Typical Electrical Installation – Wye Wiring
