Chapter 3 BFM136 Graphical Display Operations Navigation Buttons
Branch Feeder Monitor 136_Installation Operation and Manual 25
3.3.1 Display Views
The BFM136 display has 5 multi-page screen modes for viewing numerous measurement parameters
shown in the following tables. Scroll through the screen modes by briefly pressing the ENTER button.
Scroll through the display pages within the selected mode by briefly pressing the UP and DOWN buttons.
Summary/TOU Energy
Page No
Page content
Description
1
Reg.1 kWh
Trf.1 32.535
KWH
Tariff 1
2
Reg.1 kWh
Trf.2 7.465
KWH
Tariff 2
3
Reg.1 kWh
Trf.3 0.535
KWH
Tariff 3
4
Reg.1 kWh
Trf.4 0.465
KWH
Tariff 4
5
Reg.1 kWh
Trf.5 0.777
KWH
Tariff 5
6
Reg.1 kWh
Trf.6 1.535
KWH
Tariff 6
7
Reg.1 kWh
Tot. 43.312
KWH
Total
8
Reg.2 kvarh
Trf.1 0.100
kvarh
Tariff 1
9
Reg.2 kvarh
Trf.2 0.117
kvarh
Tariff 2
10
Reg.2 kvarh
Trf.3 0.235
kvarh
Tariff 3
11
Reg.2 kvarh
Trf.4 0.050
kvarh
Tariff 4
12
Reg.2 kvarh
Trf.5 0.235
kvarh
Tariff 5
13
Reg.2 kvarh
Trf.6 0.050
kvarh
Tariff 6
14
Reg.2 kvarh
Tot. 0.787
Kvarh
Total
15
Reg.3 kVAh
Trf.1 32.535
kVAh
Tariff 1
16
Reg.3 kVAh
Trf.2 7.469
kVAh
Tariff 2
17
Reg.3 kVAh
Trf.3 0.584
kVAh
Tariff 3
18
Reg.3 kVAh
Trf.4 0.468
kVAh
Tariff 4
19
Reg.3 kVAh
Trf.5 0.584
kVAh
Tariff 5
20
Reg.3 kVAh
Trf.6 0.468
kVAh
Tariff 6
21
Reg.3 kVAh
Tot. 42.575
kVAh
Total
ENTER
