Chapter 3 BFM136 Graphical Display Operations Menu Operations
Branch Feeder Monitor 136_Installation Operation and Manual 32
3.5.3 Real Time Clock Setting
This menu allows you to adjust internal real time clock.
To enter the menu, select the RTC entry from the main menu, and then press the ENTER button.
To adjust the clock:
1. Highlight a time or date item you want to change item by briefly pressing the SELECT button.
2. Adjust the selected item with the UP/DOWN buttons.
3. Highlight the next item you want to change and adjust it in the same manner.
4. To store your new date and time, press the ENTER button. If you confirm the time change while
the seconds item is highlighted, the seconds’ reading will be zeroed, otherwise seconds stay
unchanged.
To exit the menu, highlight the menu name (upper-left item) with the SELECT button, and then press the
ENTER button.
3.5.4 Basic Device Settings
This menu allows you to define the general characteristics of the electrical network.
To enter the menu, select the Basic entry from the main menu, and then press the ENTER button. For
instructions on navigating in the menu, see Viewing and Changing Setup Items.
The following table lists available options.
