Appendix E Data Scales
Branch Feeder Monitor 136_Installation Operation and Manual 71
Appendix E Data Scales
The maximum values for volts, amps and power in the BFM136 setup and in communications are limited
by the voltage and current scale settings. See Basic Meter Setup in Chapter 4 on how to change the
voltage scale in your meter.
The following table defines the meter data scales.
Scale
Range
Notes
Maximum voltage (V max)
Voltage scale  PT Ratio, V
The default voltage scale is 600V
Maximum current (I max)
HACS Primary current  2, A
The default HACS primary current is 50A
Maximum power
1
V max  I max  2, W
1
Maximum power is rounded to whole kilowatts. With PT=1.0, it is limited to 9,999,000 W.
