Appendix C Parameters for Data Monitoring and Logging
Branch Feeder Monitor 136_Installation Operation and Manual 65
Appendix C Parameters for Data Monitoring and
Logging
The following table lists parameters measured by the meter that are available for data logging and
monitoring through communications. The left column shows data abbreviations used in PAS. Parameter
groups are highlighted in bold.
Designation
Description
NONE
None (stub, read as zero)
RT PHASE
1-Cycle Phase Values
V1
V1
V2
V2
V3
V3
I1
I1 Current
I2
I2 Current
I3
I3 Current
kW L1
kW L1
kW L2
kW L2
kW L3
kW L3
kvar L1
kvar L1
kvar L2
kvar L2
kvar L3
kvar L3
kVA L1
kVA L1
kVA L2
kVA L2
kVA L3
kVA L3
PF L1
Power factor L1
PF L2
Power factor L2
PF L3
Power factor L3
V12
V12 Voltage
V23
V23 Voltage
V31
V31 Voltage
RT TOTAL
1-Cycle Total Values
kW
Total kW
kvar
Total kvar
kVA
Total kVA
PF
Total PF
PF LAG
Total PF lag
PF LEAD
Total PF lead
kW IMP
Total kW import
kW EXP
Total kW export
kvar IMP
Total kvar import
kvar EXP
Total kvar export
RT AUX
1-Cycle Auxiliary Values
In
In (neutral) Current
FREQ
Frequency
AVR PHASE
1-Second Phase Values
1
V1
V1 Voltage
V2
V2 Voltage
