Chapter 3 BFM136 Graphical Display Operations Menu Operations
Branch Feeder Monitor 136_Installation Operation and Manual 31
3. To change the HACS primary rating, highlight desired digits by
briefly pressing the SELECT button, then adjust them to the
desired value with the UP/DOWN buttons.
4. Press the ENTER button to store your selection. You return to the parameter list to select another
parameter or return to the main menu.
5. To exit the menu, highlight the menu name (upper-left item) with the SELECT button, and then
press the ENTER button.
The following table lists available options.
Label
Parameter
Options
Default
Description
Phase L1
Phase L2
Phase L3
Phase current input
terminal number
I1–I36,
None = not
connected
See note
1
Links a current input terminal to the corresponding
submeter’s phase voltage input V1, V2 or V3
CT
HACS primary current
2
1-10000 A
50 A
Specifies the primary rating of the submeter current
transformers
1
The device is pre-configured for twelve three-phase submeters.
2
Specify the HACS ratings assuming a 200% device inputs overrange. The device inputs are preset for
100A current transformers with a 50A primary rating.
3.5.2 Reset
This menu allows you to reset maximum demands in each submeter and to clear the device diagnostics.
To enter the menu, select the Reset entry from the main menu, and then press the ENTER button.
To reset the desired registers:
1. Highlight the upper-right item by briefly pressing the SELECT button.
2. Select the submeter you are going to clear with the UP/DOWN buttons.
3. Highlight the lower-left item by pressing the SELECT button.
4. Scroll through the list with the UP/DOWN buttons until the desired entry appears.
5. Press the SELECT button to highlight the lower-right item.
6. Press and hold the ENTER button for 5 seconds. The “Do” entry is replaced with “Done” showing
the operation is complete.
To exit the menu, highlight the menu name (upper-left item) with the SELECT button, and then press the
ENTER button.
The following table lists reset options.
Label
Parameter
Diag.
Clears device diagnostics status
Pow.Dmd
Clears maximum power demands
Amp.Dmd
Clears maximum ampere and volt demands
Max.Dmd
Clears all maximum demands
ResetSM 1
Diag.Do
ResetSM 4
Diag.Do
ResetSM 4
Diag.Do
ResetSM 4
Pow.DmdDo
ENTER
ResetSM 4
Pow.DmdDo
SELECT
SELECT
ResetSM 4
Pow.DmdDone
SELECT
SubMeter SM 4
Phase L1 I1
SubMeter SM 4
Phase L1 I10
ENTER
SubMeter SM 4
Phase L1 10
