Chapter 3 BFM136 Graphical Display Operations Navigation Buttons
Branch Feeder Monitor 136_Installation Operation and Manual 26
Real Time Measurements
Page No
Page content
Description
1
V1 120.5 V
Volts
2
V2 120.5 V
Volts
3
V3 120.5 V
Volts
4
V L12 208.1 V
Line to line volts
5
V L23 208.1 V
Line to line volts
6
V L31 208.1 V
Line to line volts
7
I1 neg 5.58 A
Amps. The neg label appears in the case of a reverse current connection.
8
I2 neg 7.70 A
Amps. The neg label appears in the case of a reverse current connection.
9
I3 neg 5.58 A
Amps. The neg label appears in the case of a reverse current connection.
10
Tot. kW 1.558
Total kW
11
Tot.PF 0.997
Total power factor
12
Tot. kVA 1.601
Total kVA
13
Tot. kvar 0.097
Total kvar
14
Freq. 60.00 Hz
Frequency
15
V1.Ang 0.0
I1. Ang 0.0
Phase 1 angles
16
V2. Ang -120.0
I2. Ang -120.0
Phase 2 angles
17
V3. Ang 120.0
I3. Ang 120.0
Phase 3 angles
Summary/TOU Max. Demands
Page No
Page content
Description
1
Reg.1 MD kW
Trf.1 32.535
KW maximum demand
Tariff 1
2
Reg.1 MD kW
Trf.2 7.465
KW maximum demand
Tariff 2
3
Reg.1 MD kW
Trf.3 0.535
KW maximum demand
Tariff 3
4
Reg.1 MD kW
Trf.4 0.465
KW maximum demand
Tariff 4
5
Reg.1 MD kW
Trf.5 0.535
KW maximum demand
Tariff 5
6
Reg.1 MD kW
Trf.6 0.465
KW maximum demand
Tariff 6
7
Reg.1 MD kW
Tot. 42.000
KW maximum demand
Total
8
Reg.2 MD kvar
Trf.1 0.100
kvar maximum demand
Tariff 1
9
Reg.2 MD kvar
Trf.2 0.117
kvar maximum demand
Tariff 2
10
Reg.2 MD kvar
Trf.3 0.235
kvar maximum demand
Tariff 3
ENTER
