Chapter 1 General I N F O R M A T I O N Features
PM130 PLUS Powermeter Series 13
3 voltage inputs and 3 current transformer-isolated AC inputs for
direct connection to power line or via potential and current
transformers
True RMS, volts, amps, power, power factor, neutral current, voltage
and current unbalance, frequency
Ampere/Volt demand meter
25/50/60/400 Hz measurement capabilities
Billing/TOU Energy Meter (PM130E and PM130EH)
Class 0.5S IEC 62053-22 four-quadrant active and reactive energy
polyphase static meter
Three-phase total and per phase energy measurements; active,
reactive and apparent energy counters
Time-of-Use, 4 totalization and tariff energy/demand registers x 8
tariffs, 4 seasons x 4 types of days, 8 tariff changes per day,
One–time easy programmable tariff calendar schedule
Automatic daily energy and maximum demand profile log for total
and tariff registers
Harmonic Analyzer (PM130EH)
Voltage and current THD, current TDD and K-Factor, up to 40th
order harmonic
Voltage and current harmonic spectrum and angles
Real-time Waveform Capture
Real-time “scope mode” waveform monitoring capability
Simultaneous 6-channel one-cycle waveform capture at a rate of 64
samples per cycle
Programmable Logical Controller
Embedded programmable controller
16 control setpoints; programmable thresholds and delays
Relay output control (see Available Options)
1-cycle response time
Event and Data Recording (PM130E and PM130EH)
Non-volatile memory for long-term event and data recording
Event recorder for logging internal diagnostic events and setup
changes
Two data recorders; programmable data logs on a periodic basis;
automatic daily energy and maximum demand profile log
Digital I/O
Optional four, eight or twelve digital inputs with 1-ms scan time;
automatic recording of last five digital input change events with
timestamps (see the PM130 PLUS Modbus Reference Guide)
