Chapter 5 Configuring T H E P M 1 3 0 P L U S
General M E T E R S E T U P
PM130 PLUS Powermeter Series 75
5.2 General Meter Setup
Basic Meter Setup
This section describes how to configure the PM130 PLUS for your
particular environment and application.
Before operating your meter, provide the device with basic information
about your electrical network.
Using the Front Display
Select the baSc entry from the main menu. See Viewing and Changing
Setup Options in Chapter 3 for information on configuring parameters via
the front display.
See the table below for the Basic Setup options.
Using a shortcut to the Basic Setup menu:
From the Data Display, press and release the SELECT button to enter the
primary meter menu and then simultaneously press the SELECT and UP
buttons. You are directly moved to the CT setting entry.
The shortcut is not operational if the meter is password protected.
Using PAS
Select General Setup from the Meter Setup menu. See the table below
for the Basic Setup options.
Table 19: Basic Setup Options
The wiring connection of the device
The phase potential transformer’s
primary to secondary ratio
PT Ratio multiplication factor. Used
in extra high voltage networks to
accommodate the PT ratio for
500 kV and higher networks.
The primary rating of the phase
current transformer
The nominal line frequency
Maximum Demand
Load Current
The maximum demand load
current (0 = CT primary current)
Power block demand
period
E, EH
1, 2, 3, 5, 10, 15,
20, 30, 60 min,
E=external sync
The length of the demand period
for power demand calculations. If
the external synchronization is
selected, a pulse front on the
digital input DI1 denotes the start
of the demand interval.
