Chapter 5 Configuring T H E P M 1 3 0 P L U S
General M E T E R S E T U P
PM130 PLUS Powermeter Series 91
Table 27: Display Setup Options
Display
Label
Parameter
Options
Default
Description
UPdt
Display update rate
0.1-10.0 sec
1 sec
Defines the interval
between display updates
ScrL
Auto scroll interval
None,
2-15 sec
None
Defines the scroll interval
for the main data display or
disables auto scroll
rEtn
Auto return to the
main screen
diS = disabled,
En = Enabled
Enabled
Enables automatic return to
the main display if no
buttons are pressed for 5
minutes
bAr
Reference load current
for LED bar graph
0-10,000A
(0 = CT primary
current)
0
Defines the nominal load
(100%) level for the bar
graph display
Uolt
Primary/Secondary
volts units
Pri = primary
SEc = secondary
Primary
Selects primary or
secondary units for volts
display
Ph.P
Phase powers display
mode
diS, En
Disabled
Disables or enables phase
powers in the main display
Fund.
Fundamental
component display
mode
diS, En
Disabled
Disables or enables
fundamental values in the
main display
dAtE
Date order
dnY, ndY, Ynd
(d=day, n=month,
y=year)
mm.dd.yy
Defines the date order in
the RTC display
rSt
Simple reset mode
PASS = password
protected
En = always
enabled
PASS
PASS = the simple reset is
not allowed if password
protection is enabled
En = enables the simple
reset buttons regardless of
password protection
brGt
Brightness
1-3
3
Sets the LED brightness
diAG
Diagnostic LED
diS, En
Disabled
Enables the diagnostic LED
FLSH
Flash Loader call
N/A
N/A
Launches the Flash Loader
Local Time Settings
This setup allows you to specify your time zone, daylight saving time, and
clock synchronization options.
Using the Front Display
Select rtc from the main menu. See Viewing and Changing Setup Options
in Chapter 3 for information on configuring parameters via the front
display.
Using PAS
Select General Setup from the Meter Setup menu, and then click on the
Local Settings tab.
