Appendix B A N A L O G O U T P U T P A R A M E T E R S
PM130 PLUS Powermeter Series 143
Appendix B Analog Output Parameters
The following table lists parameters that can be provided on the meter’s
analog outputs.
Table 34: Analog Output Parameters
Display Code
Designation
Description
none
NONE
None (output disabled)
1-Cycle Phase Values
rt.U1
V1/12 RT
1
V1/V12 Voltage
rt.U2
V2/23 RT
1
V2/V23 Voltage
rt.U3
V3/31 RT
1
V3/V31 Voltage
rt.U12
V12 RT
V12 Voltage
rt.U23
V23 RT
V23 Voltage
rt.U31
V31 RT
V31 Voltage
rt.C1
I1 RT
I1 Current
rt.C2
I2 RT
I2 Current
rt.C3
I3 RT
I3 Current
1-Cycle Total Values
rt. P
kW RT
Total kW
rt. q
kvar RT
Total kvar
rt. S
kVA RT
Total kVA
rt. PF
PF RT
Total PF
r.PF.LG
PF LAG RT
Total PF Lag
r.PF.Ld
PF LEAD RT
Total PF Lead
1-Cycle Auxiliary Values
r.nEU.C
In RT
In Current
rt. Fr
FREQ RT
Frequency
1-Sec Phase Values
Ar.U1
V1/12 AVR
1
V1/V12 Voltage
Ar.U2
V2/23 AVR
1
V2/V23 Voltage
Ar.U3
V3/31 AVR
1
V3/V31 Voltage
Ar.U12
V12 AVR
V12 Voltage
Ar.U23
V23 AVR
V23 Voltage
Ar.U31
V31 AVR
V31 Voltage
Ar.C1
I1 AVR
I1 Current
Ar.C2
I2 AVR
I2 Current
Ar.C3
I3 AVR
I3 Current
1-Sec Total Values
Ar. P
kW AVR
Total kW
Ar. q
kvar AVR
Total kvar
Ar. S
kVA AVR
Total kVA
Ar. PF
PF AVR
Total PF
A.PF.LG
PF LAG AVR
Total PF Lag
A.PF.Ld
PF LEAD AVR
Total PF Lead
1-Sec Auxiliary Values
A.nEU.C
In AVR
In Current
Ar. Fr
FREQ AVR
Frequency
Demands
E, EH
Acd.P.i
kW IMP ACD
Accumulated kW import demand
Acd.P.E
kW EXP ACD
Accumulated kW export demand
