Chapter 1 General I N F O R M A T I O N Customized O P T I O N S
16 PM130 PLUS Powermeter Series
A precise clock with battery backup; 6-year clock retention time
4 dry contact digital inputs (DI) for monitoring external contacts and
receiving pulses from energy, water and gas meters; programmable
de-bounce time; 1-ms scan time.
1.3 Customized Options
Presentation of data on the front display and via communications can be
customized to best suit the user application.
Device Resolution
A low or high-resolution option can be selected for the presentation of
voltage, current, and power for use in high and low power applications.
See Measurement Units for more information.
Energy Rollover
The energy rollover limit can be changed in the meter to provide 4-digit to
9-digit energy resolution. See Device Options in Chapter 5 for details. The
meter display is capable of showing full 9-digit energy counters using two
LED windows.
Display Options
Different display options are available for customization to be used in dark
or non-safe locations, or in places that are hardly accessible for
observation. See Configuring the Display in Chapter 5 for more
information.
1.4 Measured Parameters
Table 1: Measured and Displayed Parameters
1-cycle Real-time Measurements
Voltage & Current unbalance
1-sec Average Measurements
