Appendix C S E T P O I N T T R I G G E R S A N D A C T I O N S
PM130 PLUS Powermeter Series 145
Appendix C Setpoint Triggers and
Actions
Table 35: Setpoint Triggers
Display Code
Designation
Description
nonE
NONE
None (condition is not active)
Status Inputs
S1.On
STAT INP #1 ON
Status input #1 ON
S2.On
STAT INP #2 ON
Status input #2 ON
S3.On
STAT INP #3 ON
Status input #3 ON
S4.On
STAT INP #4 ON
Status input #4 ON
S1.OFF
STAT INP #1 OFF
Status input #1 OFF
S2.OFF
STAT INP #2 OFF
Status input #2 OFF
S3.OFF
STAT INP #3 OFF
Status input #3 OFF
S4.OFF
STAT INP #4 OFF
Status input #4 OFF
Relays
r1.On
RELAY #1 ON
Relay #1 ON
r2.On
RELAY #2 ON
Relay #2 ON
r1.OFF
RELAY #1 OFF
Relay #1 OFF
r2.OFF
RELAY #2 OFF
Relay #2 OFF
Phase Reversal
POS.P.r
POS PHASE REVERSAL
Positive phase rotation reversal
nEG.P.r
NEG PHASE REVERSAL
Negative phase rotation reversal
Low/High 1-Cycle Values on any Phase
r.Hi. U
HI VOLT RT
1
High voltage
r.Lo. U
LO VOLT RT
1
Low voltage
r.Hi. C
HI AMPS RT
High current
r.Lo. C
LO AMPS RT
Low current
r.thd.U
HI V THD
2
High voltage THD
r.thd.C
HI I THD
2
High current THD
r.HFc.C
HI KF RT
High K-Factor
r.tdd.C
HI I TDD
High current TDD
1-Cycle Auxiliary Values
r.Hi.Fr
HI FREQ RT
High frequency
r.Lo.Fr
LO FREQ RT
Low frequency
r.U.Unb
HI V UNB% RT
1
High voltage unbalance
r.C.Unb
HI I UNB% RT
High current unbalance
1-Sec Phase Values
A.Hi.C1
HI I1 AVR
High I1 current
A.Hi.C2
HI I2 AVR
High I2 current
A.Hi.C3
HI I3 AVR
High I3 current
A.Lo.C1
LO I1 AVR
Low I1 current
A.Lo.C2
LO I2 AVR
Low I2 current
A.Lo.C3
LO I3 AVR
Low I3 current
1-Sec Values on any Phase
A.Hi. U
HI VOLT AVR
1
High voltage
A.Lo. U
LO VOLT AVR
1
Low voltage
A.Hi. C
HI AMPS AVR
High current
A.Lo. C
LO AMPS AVR
Low current
1-Sec Total Values
