Chapter 1 General I N F O R M A T I O N Available O P T I O N S
14 PM130 PLUS Powermeter Series
Optional two or four relay outputs with 1-cycle update time;
unlatched, latched, pulse and KYZ operation; energy pulses
Display
Easy to read 3-row (2x4 characters + 1x5 characters) bright LED
display, adjustable update time and brightness
Auto-scroll option with adjustable page exposition time; auto-return
to a default page
LED bar graph showing percent load with respect to user-definable
nominal load current
Real-time Clock
Internal clock with 20-second retention time
Optional battery-operated clock unit (see Available Options)
Communications
Standard 2-wire RS-485 communication port; Modbus RTU, DNP3,
SATEC ASCII communication protocols and IEC 61870-5-101
Optional second communication port (see Available Options);
Modbus RTU, Modbus/TCP, DNP3, DNP3/TCP, IEC 61870-5-101/104,
SATEC ASCII and Profibus DP communication protocols
eXpertPower client for communicating with the SATEC proprietary
eXpertPower Internet services (with the Ethernet or GPRS module),
see Setting Up eXpertPower Client)
TCP notification client for communicating with a remote Modbus/TCP
server on events or periodically on a time basis (with the Ethernet or
GPRS module), see Setting Up TCP Notification Client)
Meter Security
Password security for protecting meter setups and accumulated data
from unauthorized changes
Upgradeable Firmware
Easy upgrading device firmware through a serial or Ethernet port.
Software Support
PAS – free meter configuration and data acquisition tool
eXpertPower
TM
– SATEC proprietary Internet services
1.2 Available Options
The PM130 PLUS can be provided with an optional expansion module from
the following list:
Digital I/O
Analog outputs
TOU - Battery-operated clock unit
Ethernet communication port
Profibus DP communication port
RS-232/RS-422/RS-485 communication port
