Chapter 3 Using F R O N T D I S P L A Y Data D I S P L A Y
52 PM130 PLUS Powermeter Series
V3/V31
10
MAX
DMD
I1
I2
I3
Maximum ampere demands
11
MAX
DMD
kVA/MVA
PF
kW/MW
Maximum VA demand
PF at maximum VA demand
Maximum W demand
12
MAX
DMD
A neut.
var
Maximum neutral current demand
Maximum var demand
Table 6: Min/Max and Maximum Demands (Amp-Demand version)
1
MAX
DMD
I1
I2
I3
Maximum ampere demands
2
MAX
DMD
A neut.
Maximum neutral current demand
Harmonics Display (PM130EH)
1. Press the H/ESC button.
The THD/TDD LED is illuminated.
2. Use the UP and DOWN arrow buttons to scroll through total
harmonics measurements.
3. Press the H/ESC button again to move to the individual harmonics.
Note that voltage harmonics readings are line-to-neutral in the 4LN3,
3LN3, 3BLN3 wiring modes, and line-to-line in all other modes.
Table 7: Total Harmonics
1
thd.
V1/V12 THD
V2/V23 THD
V3/V31 THD
Voltage THD
2
thd.
I1 THD
I2 THD
I3 THD
Current THD
3
tdd.
I1 TDD
I2 TDD
I3 TDD
Current TDD
4
HF
I1 K-Factor
I2 K-Factor
I3 K-Factor
Current K-Factor
Table 8: Individual Voltage Harmonics
1
3.
V1/V12 HD%
V2/V23 HD%
V3/V31 HD%
Order 3 harmonic distortion
2
5.
V1/V12 HD%
V2/V23 HD%
V3/V31 HD%
Order 5 harmonic distortion
…
