Chapter 9 Viewing F I L E S Viewing O P T I O N S
132 PM130 PLUS Powermeter Series
3. Click OK.
Working with Tables
Selecting Font and Grid
To change the table font or a type of the grid lines:
1. Click with right mouse button on the table, select Options and click
on the Table tab.
2. Select the font type and size and how you wish the table grid to be
shown.
3. Click OK.
Selecting Primary and Secondary Units
Voltages and currents can be displayed in primary or secondary units.
To change units, click on the table with the right mouse button, select
Options, select the desired units for voltages and currents, and then click
OK.
Copying a Table
To copy the entire table, or its part, into the Clipboard or into another
application such as Microsoft Excel or Word:
1. Click on the data window with the right mouse button and choose
Select All, or click on the upper-left corner of the table (where the
“No.” label is commonly displayed).
2. Click with the right mouse button on the window again and choose
Copy, or click on the Copy button on the PAS toolbar.
3. Run the application to which you want to copy data, position the
cursor at the correct place.
4. Click the Paste button on the application's toolbar or select
Paste from the Edit menu.
When copying, table columns are separated by a tab character.
Printing a Table
To check how your document appears on a printed page, select Print
Preview from the File menu.
To print a table to a printer, click on the print button
on the toolbar,
select a printer and click OK.
Working with Graphic Windows
Selecting Channels
To select the channels you want to view on the screen, click on the graph
window with the right mouse button, select Channels..., check the
channels you want displayed, and then click OK.
Checkboxes for channels that are not available in the present view are
dimmed.
Selecting Primary and Secondary Units
Voltages and currents can be displayed in primary or secondary units.
To Next Page
