Chapter 1 General I N F O R M A T I O N Measured P A R A M E T E R S
PM130 PLUS Powermeter Series 17
Parameter
Display
Comm.
Analog
Pulse
Alarm
Total kVA




Total Power Factor




Frequency




Neutral Current




Voltage & Current unbalance



Amps & Volt Demands
Ampere & Volt Demand per phase


Ampere Maximum Demand per phase



Voltage Maximum Demand per phase



Power Demands
E, EH
kW Accumulated Demand Import & Export



kvar Accumulated Demand Import & Export



kVA Accumulated Demand



kW Demand Import & Export


kvar Demand Import & Export


kVA Demand


kW Sliding Demand Import & Export


kvar Sliding Demand Import & Export


kVA Sliding Demand


kW Predicted Demand Import & Export


kvar Predicted Demand Import & Export


kVA Predicted Demand


kW Maximum Demand Import


kW Maximum Demand Export

kvar Maximum Demand Import


kvar Maximum Demand Export

kVA Maximum Demand


Total Energy
E, EH
Total kWh Import & Export



Total kvarh Import & Export



Total kvarh Net

Total kVAh



Energy per Phase
E, EH
kWh Import per phase


kvarh Import per phase

kVAh per phase


TOU Registers
E, EH
4 TOU energy registers (kWh and kvarh
import & export, kVAh, 4 pulse sources)


4 TOU maximum demand registers

8 tariffs, 4 seasons x 4 types of day


Harmonic Measurements
EH
Voltage THD per phase




Current THD per phase




Current TDD per phase




K-factor per phase




Voltage harmonics per phase up to order 40


Current harmonics per phase up to order 40


Voltage harmonic angles up to order 40

Current harmonic angles up to order 40

Fundamental Component
EH
