Chapter 5 Configuring T H E P M 1 3 0 P L U S
General M E T E R S E T U P
92 PM130 PLUS Powermeter Series
Figure 5-13: General Setup Dialog Box – Local Settings Tab
The available options are described in Table 28.
Table 28: Local Time Options
Display
Label
Parameter
Options
Default
Description
-
Country
Default, or country
name
Default
Defines calendar setting.
The default setting stands
for the U.S.A.
dSt
Daylight Saving Time
diS = disabled
En = enabled
Disabled
When DST is disabled, the
RTC operates in standard
time only. When enabled,
the meter automatically
updates the time at the pre-
defined DST switch dates.
dSt.S
DST Start Month
DST Start Week
DST Start Weekday
Month-week-weekday
Week = 1, 2, 3, 4 or L
(last week of the month)
Second
Sunday in
March
The date when Daylight
Saving Time begins.
dSt.S
Hour
DST Start Hour
1-6
2
The hour when Daylight
Saving Time begins.
dSt.E
DST End Month
DST End Week
DST End Weekday
Month-week-weekday
Week = 1, 2, 3, 4 or L
(last week of the month)
First Sunday
in November
The date when Daylight
Saving Time ends.
dSt.E
Hour
DST End Hour
1-6
2
The hour when Daylight
Saving Time ends.
SYnC
Time
Synchronization
Input
None
di.1 = DI1
di.2 = DI2
di.3 = DI3
di.4 = DI4
None
The external port receiving
the time synchronization
pulses
