Initiating connection from the DLOADX program, but with the control panel
calling back and establishing connection
This method ensures better security of the system, because the control panel may
only be remotely programmed from a specified locality. Make sure that in the control
panel:
• you have programmed telephone number of the computer from which the control
panel is to be programmed (SERVICE MODE X0. SRVMOD CONFIG X4. DLOADX TEL.);
• the ANSWERING – MODEM option is enabled (SERVICE MODE X3. GLOBAL PARAM.
X1. OPTIONS XMODEM ANSWERING);
• you have defined the number of rings after which the control panel will go off-hook
(SERVICE MODE X7. ANSWERING X1. RINGS TO ANS.);
• you have defined whether the control panel will go off-hook after the first, or after the
second call (SERVICE MODE X3. GLOBAL PARAM. X1. OPTIONS XDOUBLE CALL).
Telephone number of the control panel must be programmed in the DLOADX program.
1. Start the DLOADX program on computer.
2. Initialize the modem connected to the computer. For the modem to be initialized,
click on the button and, from the menu that will be displayed, select the 300 bps
modem. The window will then open where the modem initializing information will be
shown.
3. Click on the "Connect" button.
4. After the preprogrammed number of rings (after the second call, if the DOUBLE CALL
option is enabled), the control panel will answer the call, acknowledge receiving the
connection, and then disconnect.
5. The control panel will call back the number programmed in the control panel and the
connection will be established, which will be indicated by the DLOADX program by an
appropriate message.
Initiating connection by the control panel
Like the previous method, also this one ensures enhanced security of the system,
because the control panel may only be remotely programmed from a specified locality. It
can be applied if the system user prefers that the remote programming cannot be
carried out without his knowledge. Telephone number of the computer from the control
panel is to be programmed must be programmed in the control panel (S
ERVICE MODE
X0. S
RVMOD CONFIG X4. DLOADX TEL.).
1. Start the D
LOADX program on computer.
2. Initialize the modem connected to the computer. For the modem to be initialized,
click on the button and, from the menu that will be displayed, select the 300 bps
modem. The window will then open where the modem initializing information will be
shown.
3. Enter in the keypad the service code (by default 12345) or the code of user having
the DOWNLOAD/SERVICE privilege and press the key.
4. Press in turn the keys (the START DWNLTEL con. function will
start).
5. The D
LOADX program will signal establishing communication by an appropriate
message.
