Additionally, the ACX-201 expander will send information on:
• status of AUX1 and AUX2 power supply outputs – information on overload is sent when
the load current of AUX1 or AUX2 output exceeds 0.5 A.
• battery status – information on low battery will be sent when the battery voltage drops
below 11 V for more than 12 minutes (3 battery tests). The information will be sent to the
controller when the battery voltage rises above 11 V more than 12 minutes (3 battery
tests).
• AC supply status – information on the loss of power supply will be sent when the AC
power loss lasts for more than 30 seconds. The AC supply restore is reported with the
same delay.
7.2.5 230 V AC wireless controllers – general rules of programming
Activation of the output to which the controller is assigned will result in energizing the 230 V
electrical circuit (if reverse polarity of the output has been programmed, the circuit will be
deenergized).
Depending on the operating mode, information on the button status (mode 0) or on the
electrical circuit status (mode 1 and mode 2) will be sent to the control panel zone to
which the controller is assigned. Information on the button status is being sent in on-line
mode. Information on the electrical circuit status is sent during the response time.
Pressing the button/closing the electrical circuit means violation of the zone to which the
controller is assigned.
Be careful when selecting the F
ILTER value for ASW-100 E or ASW-100 F controller, i.e. the
number of unanswered response periods after which the loss of communication with the
controller will be reported. As the 230 V sockets are installed at low height, the controllers
mounted in them are subject to the risk of being covered by people moving around the
facility.
7.2.6 Configuration of wireless devices by means of the DLOADX program
In the DLOADX program, parameters of the wireless devices are configured in the "Versa –
Structure" window, "Hardware" tab, after selecting the ACU-100 controller in the list of
devices. Click on the "Read" button in the table to display the list of wireless devices
available in the system. In order to save the new setting of wireless devices, click on the
"Write" button situated below the table (the
and buttons in the main menu of the
D
LOADX program are not provided for reading/writing the settings of wireless devices
supported by the controller). Described below is the procedure of programming additional
parameters and options for wireless devices, available in the "Configuration" column.
APD-100 detector
For detectors with firmware version 2.01, enter a 2-digit sequence. The first digit relates to
sensitivity (see: Table 8), and the second one – to the pet immunity option (0 – option
disabled, 1 – option enabled). For detectors with older firmware, enter a digit from 1 to 3,
which corresponds to the selected sensitivity (see: Table 8).
Digit Detector sensitivity
1 low
2 medium
3 high
Table 8.
