6.4 Output options
Clearing from partition 1 / Clearing from partition 2 – depending on the output function:
– alarm outputs – the alarm can be cleared by users having access to the selected
partition,
– outputs 1. EXTERNAL SIREN and 2. INTERNAL SIREN with enabled
ARMING/DISARMING/CLEARING SIGNALING option – the output will be activated when the
selected partition is armed/disarmed, or when alarm is cleared in it.
Partition 1 / Partition 2 – depending on the output function:
– 12. POWER SUPPLY ON ARMED – the output is active when the selected partition is armed
(it activates on arming, without taking the exit delay into account),
– 15. CONTROLLED – the output can be controlled by the users having access to the
selected partition by means of the user function 8. CONTROL (if no partition is selected,
the function 8. CONTROL will not be available in the keypad),
– 17. EXIT DELAY STATUS – the output is active when the exit delay countdown is running in
the selected partition,
– 18. ARMED STATUS – the output is active when partition/partitions is/are armed (see:
parameter ACTIVATION: PARTITION ARMED MODE and option ONE PARTITION ARMED
SIGNALING
).
Reset in partition 1 / Reset in partition 2 – the output with function 13. ZONE VIOLATION, in
which the CUT-OFF TIME equal to 0 is programmed, can be reset with the OUTPUTS RESET
user function by the users having access to the selected partition.
Pulse – output with pulsating mode of operation (0.5/0.5 sec.). This option refers to the
outputs for which the cut-off time is to be programmed (except for the OUTPUTS
1. EXTERNAL SIREN and 2. INTERNAL SIREN).
Polarity +12V – activation results in switching on the device connected to the output. If the
option is disabled (reverse polarity), will result in switching off the device connected to the
output (the device will be switched on, when the output is inactive).
high-current output
option enabled
(normal polarity)
option disabled
(reverse polarity)
active state
+12V voltage supplied +12V voltage cut off
inactive state
+12V voltage cut off +12V voltage supplied
low-current output
option enabled
(normal polarity)
option disabled
(reverse polarity)
active state
shorted to ground disconnected from ground
inactive state
disconnected from ground shorted to ground
Table 6. Mode of output operation depending on the POLARITY +12V option.
Fire alarms signaling – option for the OUTPUTS 1. EXTERNAL SIREN and 2. INTERNAL SIREN.
The output signals in pulsating mode the fire alarms from selected zones (see: ACTIVATION:
ZONES
) and partitions (see: output options ALARM SIGNALING – PARTITION 1 and ALARM
SIGNALING
– PARTITION 2).
One partition armed signaling – option for the output 18. ARMED STATUS, active when the
PARTITION 1 and PARTITION 2 options are enabled. The output indicates armed mode when
