50 Programming Manual SATEL
2. Determine whether the detector is to be always active ( – option disabled, – option
enabled). Press
.
3. Using the
and keys, select which of the two reed switches of the magnetic
contact (lower or side) is to be active. Press key .
Then select the second zone to which the detector is assigned and:
1. Enter a digit from the 1 to 8 range, corresponding to the selected sensitivity of vibration
detector. Press .
2. Enter a digit from the 1 to 7 range, corresponding to the number of pulses, the recording
of which will result in violation of the vibration detector. Press .
ASD-100 detector
1. Enter an appropriate value for the FILTER and press .
2. Using the and keys, define operating mode of the heat detectors. Press
.
3. Using the
and keys, define operating mode of the buzzer ( – acoustic
signaling disabled; 1, 2 or 3 – type of acoustic signaling). Press .
4. Using the and keys, determine the time of alarm signaling by the detector
(buzzer or LED). Press .
ASP-105 siren
1. Enter an appropriate value for the FILTER and press .
2. Using the and keys, select the type of acoustic signaling. Press .
3. Using the and keys, determine the time of alarm signaling. Press .
ASP-205 siren
In the event of the ASP-205 siren, two types of signaling are to be programmed. Select the
first zone to which the siren is assigned to program the signaling triggered by the first siren
control output. Select the second zones to program the signaling triggered by the second
siren control output. In both cases, the process of configuration is almost identical (except
that the F
ILTER parameter is not programmed for the second zone).
1. Enter an appropriate value for the F
ILTER and press .
2. Using the and keys, select the operating mode of acoustic signaling ( –
acoustic signaling disabled; 1, 2 or 3 – type of acoustic signaling). Press
.
3. Using the and keys, determine the duration of acoustic signaling. Press
.
4. Define whether the optical signaling is to be enabled ( – signaling disabled, –
signaling enabled). Press .
ASW-100 E and ASW-100 F controllers
1. Enter an appropriate value for the FILTER and press .
2. Using the and keys, select operation mode for the button ("inactive " – the
electric circuit is only remotely controlled; "interim control" – the electric circuit may be
controlled remotely or manually; "combined control" – the electric circuit may be controlled
remotely or manually, but the remote control can be blocked manually). Press .
7.3 Proximity card reader
LED R – reaction of the partition after removal of the card from the reader, when the red LED
is lit. The partition can be fully armed or its status may remain unchanged.
