SATEL VERSA 55
– Long kiss-off signal – the control panel will accept a long acknowledgement signal
for receiving events in case of Ademco Express and Contact ID formats. Enable this
option if the monitoring station acknowledges receiving events in a non-standard
way (the kiss-off signal is longer than 800 ms).
– SIA – send partition name – in the SIA format, the name of partition where the
event took place will also be sent, in addition to the event code.
– SIA – send event source name – in the SIA format, the name of event source
(zone, user, etc.) will also be sent, in addition to the event code.
– SIA – confirm each block – the control panel will wait for acknowledgement by the
monitoring station of receiving every data block sent in the SIA format.
– SIA – identifier confirmation required – the control panel will wait for
acknowledgement by the monitoring station of receiving the identifier with which the
data were sent.
Test transmissions – the test transmission may be sent:
– at a specified time. The test transmission code is sent regularly at a defined time. The
number of days between transmissions and the time of sending transmission are
programmed. Programming the value 0 for days means that the transmission will be
sent everyday (in the same way, as in case programming the value 1).
– in specified time intervals. The test transmission code is sent after expiry of a defined
time after the last transmission (irrespective of whether it was a test transmission or a
code of another event was sent). The test transmission of this type may be sent in other
time intervals, when the control panel is armed (which requires programming some
additional parameters). The number of days, hours and minutes between transmissions
are to be programmed.
All types of test transmission may be programmed simultaneously.
9.2 Event codes
For the pulse and Ademco Express formats, it is necessary to program codes which will be
sent to the monitoring station if the defined events occur. The reported events are those for
which a code different from "00" has been programmed. 2 hexadecimal characters (digits or
letters from A to F) are to be programmed.
For the Contact ID and SIA formats, event codes consistent with format specification are
sent. In case of the CONTACT ID (SELECTED) and SIA (SELECTED), the codes must be
programmed at the events which are to be reported (not the programmed code, but a code
consistent with the format specification will be sent).
9.3 Starting the reporting
Before you proceed to the programming, obtain from the monitoring station operator all data
necessary to correctly start the reporting function:
• telephone number of the monitoring station,
• transmission format required by the monitoring station,
• identifiers assigned to the alarm system,
• list of event codes (not applicable to Contact ID and SIA formats).
1. Enable the REPORTING – TELEPHONE option (see: GLOBAL OPTIONS).
2. Determine how the telephone numbers should be dialed (global option TONE DIALING; in
case of the pulse dialing option – PULSE 1/1,5 (OFF 1/2)).
