34 Programming Manual SATEL
6. Outputs
There can be up to 12 outputs in the system:
• hardwired – on the control panel PCB and in the expander. The number of available
hardwired zones is determined by the control panel during the identification procedure.
• wireless – after connection of the ACU-100 controller. The number of available wireless
zones depends on the number of wireless devices registered in the system and is
determined during the procedure of adding the same.
In the DLOADX program, the parameters and options of outputs are programmed in the
"Versa – Outputs" window (see: Fig. 10).
In the keypad, the parameters and options of outputs are configured by means of the
OUTPUTS function (SERVICE MODE X2. HARDWARE X3. OUTPUTS). Programming is performed
by means of the "step by step" method (the numbers are displayed in binary mode on the
and LEDs of the first and second partition):
1. Select output.
2. Output function.
3. Cut-off time.
4. Triggering zones [actually, the partition armed mode is selected for the output with
function 18. ARMED STATUS, and the troubles for the output with function 19. TROUBLE
STATUS
(see: Section OUTPUT PARAMETERS)].
5. Output options.
6. Output name [only in LCD keypad].
6.1 Numeration of outputs in the system
The control panel supports outputs having numbers from 1 to 12. The numbers of hardwired
and wireless outputs may coincide. The control panel will support them simultaneously.
6.1.1 Hardwired outputs
The hardwired outputs are assigned numbers automatically:
• the outputs on control panel main board have numbers from 1 to 4;
• the outputs in expander have numbers from 5 to 12.
6.1.2 Wireless outputs
The wireless outputs can be assigned numbers from 1 to 30. The numbers are assigned
during the procedure of adding wireless devices (the output number is the same as the
number of selected zone). You should bear in mind that the control panel does not support
the outputs with numbers from 13 to 30.
6.2 Output functions
0. NOT USED
1. E
XTERNAL SIREN – signals the burglary, panic and tamper alarms.
2. I
NTERNAL SIREN – signals the burglary, panic and tamper alarms, as well as the warning
alarms.
Note: The way of signaling the tamper alarms by the outputs with functions 1. EXTERNAL
SIREN
and 2. INTERNAL SIREN depends on the global options TAMPER ALARM ALWAYS
AUDIBLE
and TAMPER ALARM ON INTERNAL SIRENS.
3. BURGLARY – signals the alarms from zones with reaction types from 0 to 7.
