38 Programming Manual SATEL
any of the two partitions is armed (if the option is disabled, only when both partitions are
armed).
Arming/Disarming/Clearing signaling – option for the outputs 1. EXTERNAL SIREN and
2. INTERNAL SIREN (see also: output options CLEARING FROM PARTITION 1 and CLEARING FROM
PARTITION
2 and global option ARMING/DISARMING/CLEARING SIGNALING FROM ZONES ONLY).
The output signals arming and disarming as well as alarm clearing. Arming is signaled by
one pulse, disarming – by two pulses, and alarm clearing – by four pulses. Pulse duration
is approx. 0.3 second.
Alarm signaling – partition 1 / Alarm signaling – partition 2 – an option for the alarm
outputs. The output signals the selected partition alarms which were not triggered by
zones.
Timer 1 / Timer 2 / Timer 3 / Timer 4 – options for the 15. CONTROLLED outputs. The output
is controlled by selected timer (switch on the timer to activate the output for the CUT-OFF
TIME
).
LED
Name displayed on
LCD keypad
Options
Output
function
Clearing from partition 1 1-10
Partition 1 12, 15, 17, 18
1
Part.1 clears
Reset in partition 1
13
Clearing from partition 2
1-10
Partition 2 12, 15, 17, 18
2
Part.2 clears
Reset in partition 2 13
3
Pulsation Pulse 3-10, 13-15
4
Polarization + Polarity +12V all
Fire alarms signaling 1, 2
Timer 1 15
5
Fire alarm
One partition armed signaling
18
Arming/Disarming/Clearing signaling 1, 2
6
Arm/dArm/Cl.chrp
Timer 2
15
Alarm signaling – partition 1
1-10
7
Part.1 alarms
Timer 3 15
Alarm signaling – partition 2 1-10
8
Part.2 alarms
Timer 4
15
Table 7. The way of presenting output options in keypads. The options in the graphic mode in
the LCD keypad are numbered in the same way as in the LED keypad.
6.5 Quick control of outputs
If the quick control of the outputs 15. CONTROLLED is to be available in keypads, the outputs
of this type must be assigned to the corresponding keypad keys. One output can be assigned
to each of the keys designated with numerals. To activate that output, press the key with
respective numeral and confirm using the key, and to deactivate the output, press the
same key and confirm using the key.
