5.1 Numeration of system zones
5.1.1 Hardwired zones
Numbers are assigned to the hardwired zones automatically:
• the zones on control panel PCB always have initial numbers (1-5 for the VERSA 5 control
panel; 1-10 for the VERSA 10 control panel; 1-15 for the VERSA 15 control panel);
• the zones in expanders are numbered depending on the address which is set in them:
– expander with address 12 (0Ch) – numbers from 7 to 14;
– expander with address 13 (0Dh) – numbers from 15 to 22;
– expander with address 14 (0Eh) – numbers from 23 to 30.
If the expander zones coincide with those on the control panel PCB, you may define which of
the zones will be supported by the mainboard, and which ones by the expander. In the
keypad, the VERSA ZONES service function (SERVICE MODE X2. HARDWARE X7. VERSA
ZONES
) is provided for this purpose. In the DLOADX program, this can be done in the "Versa –
Structure" window, "System" tab, when programming the selected zone.
5.1.2 Wireless zones
The wireless zones may be assigned any numbers in the system. The numbers are assigned
during the procedure of adding wireless devices. When the wireless zone number coincides
with that of the hardwired zone, you may define which of the zones is to be supported. In the
keypad, the ACU-100 ZONES service function (SERVICE MODE X2. HARDWARE X1. KPDS &
EXPS
. X3. ACU-100 X4. ACU-100 ZONES). is provided for this purpose. In the DLOADX
program, this can be done in the "Versa – Structure" window, "System" tab, when
programming the selected zone.
5.2 End of line resistors
For the zones on mainboard and in zone expanders identified by the control panel as
CA-64 Ei and CA-64 EPSi, the value of resistors used in the EOL and 2EOL configurations is
programmable within the range from 500 Ω to 15 kΩ.
In the D
LOADX program, the resistor value should be entered in the "Versa – Structure"
window, "Hardware" tab, after indicating the mainboard or selected zone expander in the list.
In the keypad, the resistor value should be programmed as follows:
– for mainboard – by means of the EOL
1 RESISTOR and EOL 2 RESISTOR function
(S
ERVICE MODE X2. HARDWARE X5. EOL 1 RESIST. / X6. EOL 2 RESIST.).
– for zone expander – during configuration of the expander by using the SETTINGS
function (S
ERVICE MODE X2. HARDWARE X1. KPDS & EXP. X2. SETTINGS ).
Notes:
• The sum of values programmed for the resistors R1 and R2 may not be lower than 500
Ω
or higher than 15 k
Ω
.
• In case of the zone expander, it is possible to program the value 0 for the resistor R2. The
2EOL configuration requires that two resistors be used, each having resistance equal to
half the value defined for the resistor R1.
• In the EOL configuration, the resistance value is equal to the sum of values programmed
for the resistors R1 and R2.
5.3 Zone parameters
Zone name – individual name of zone (up to 16 characters).
