18 User Manual SATEL
To terminate the function of partition status presentation, press the key. The keypad
will exit the function automatically after 2 minutes.
6.10 Triggering the alarm from keypad
The installer may permit the alarms being triggered by means of respective keypad keys.
6.10.1 Triggering fire alarm
Press and hold down the key for approx. 3 seconds.
6.10.2 Triggering medical (auxiliary) alarm
Press and hold down the key for approx. 3 seconds.
6.10.3 Triggering panic alarm
Press and hold down the key for approx. 3 seconds.
6.11 Enabling/disabling the chime signal
The keypad may signal violation of selected zones by a sequence of five short beeps. The
installer defines the zones whose violation will be signaled. The zone violation will not be
signaled if it results in triggering alarm. The user can enable/disable chime signaling, if such
an option is allowed for by the installer. To enable/disable the chime signaling, press and
hold down the key for approx. 3 seconds. 3 short beeps indicate that the signaling is
disabled. 4 short beeps and 1 long beep indicate that the signaling is enabled.
6.12 User menu
To enter the user menu, enter the code and press the key. Entering the menu will be
confirmed by 2 short beeps and the
LED will start blinking (the LED is blinking during
navigation through the menu and submenus, and is steadily lit when any function is running).
In the LCD keypad, the first of the available functions will be displayed. The list of available
functions depends on the user rights and the system state. Press the key to quit the
user menu. The keypad will quit the user menu automatically, if 2 minutes have elapsed
since the last key was pressed.
6.12.1 Access to functions by using arrow keys
This way of starting the function is only available in the LCD keypad.
1. Use the and keys to find the required submenu (the shape of submenu
cursor is: ) or function (the shape of function indicating cursor is: ).
2. Press the or key to enter the submenu (use the key to return to the
previous menu/submenus) or function. Entering a submenu or function is signaled by two
short beeps.
6.12.2 Access to functions by using numerical shortcuts
Each keypad will allow you to navigate throughout the menu and run functions using this
method. All submenus and functions are numbered. In order to enter a submenu, just press
the key with number corresponding to the submenu number. In order to start a function,
press the key with number corresponding to the function number, and then the key.
You can quickly start the selected function by entering at once a sequence of some digits
(corresponding to the consecutive submenu numbers and the function number) and
confirming them by pressing the key. Entering a submenu or function is signaled by
two short beeps.
