12. Brief Description of Operating the System with a Keypad
lit – partition armed
blinking – partition exit delay countdown
information on alarm or alarm memory acc. to repeating
scheme of 2-second duration:
– fire alarm,
–
burglary alarm,
– warning alarm,
– tamper alarm,
– fire alarm memory,
–
burglary alarm
memory,
– warning alarm memory,
– tamper alarm memory.
(
– LED OFF; – LED ON)
blinking – system requires user's attention – use
the 7. S
YSTEM STATE user function to find out the
cause of LED blinking
information on service mode:
lit – service menu in this keypad
blinking – service menu in another keypad
LCD keypad
LCD display showing the date and hour or zone
status (press and hold down the
key for
approx. 3 sec. to change displayed information):
b – zone inhibited,
b [blinking] – zone isolated,
L – long zone violation,
N – no zone violation,
! – zone that first triggered alarm,
– zone tampered (2EOL type zone),
– zone violated,
t – tamper memory (2EOL type zone),
a – alarm memory,
– normal zone status.
Some symbols are not displayed in armed mode.
LED keypad
LEDs presenting the zone status acc. to
repeating scheme of 2-second duration:
– zone inhibited,
– zone isolated,
– long zone violation,
– no zone violations,
– zone that first triggered alarm,
– tamper memory (2EOL type
zone),
– zone violated,
– tamper memory (2EOL type
zone),
– alarm memory,
– normal zone status.
(
– LED OFF; – LED ON)
Some information is not presented in armed
mode.
