SATEL VERSA 37
– partition status (disarmed/armed mode) – this information is always presented.
If the GRADE 2 option is not enabled, only information about troubles is displayed.
6.23.1 Trouble list
The display in LCD keypad provides information on troubles in the form of messages. The list
can be scrolled through by using the and keys. In case of the LED keypad,
information about troubles is provided by means of LEDs designated with numbers. The
following troubles are indicated by respective LEDs going on:
LED 1 - loss of 230 V AC power;
LED 2 - no battery or low battery;
LED 3 - no voltage on telephone line;
LED 4 - no signal or intermittent signal on telephone line;
LED 5 - OUT1 output overloaded;
LED 6 - OUT2 output overloaded;
LED 7 - KPD supply output overloaded;
LED 8 - AUX supply output overloaded;
LED 9 - problem with (telephone or Ethernet) reporting to Station 1;
LED 10 - problem with (telephone or Ethernet) reporting to Station 2;
LED 11 - jamming ABAX system wireless devices; ETHM-1 module initialization error;
Ethernet network not available; no communication with device selected for
communication test (PING); radio receiver fails to receive more events from INT-
TXM module;
LED 12 - short-circuit in communication bus;
LED 13 - control panel clock trouble;
LED 14 - control panel settings trouble;
LED 15 - violation of tamper zone (TMP zone on control panel main board or 6. 24H
TAMPER
type zone);
LED 16 - zone tamper;
LED 17 - too long zone violation;
LED 18 - no zone violation;
LED 19 - violation of 11. DETECTOR MASK or 19. TROUBLE type zones;
LED 20 - low battery in wireless device;
LED 21 - no communication with wireless device;
LED 22 - expander tamper;
LED 23 - no presence of expander;
LED 24 - loss of 230 V AC power in expander;
LED 25 - no battery or low battery in expander;
LED 26 - expander supply output overloaded;
LED 27 - low battery in user keyfob;
LED 28 - expander restart;
LED 29 - control panel restart;
LED 30 - trouble in control panel processor system (HSE).
6.23.2 Trouble handling procedure
Each trouble poses a danger to proper functioning of the alarm system and should be
repaired as soon as possible. If the repair of trouble by the user is impossible, the service
technician must be called in.
