SATEL VERSA 39
LCD keypad
After starting the function, information on the first of the 15. CONTROLLED type outputs
will be displayed, the output number being shown in the upper line and the output name
in the lower line of display. You can scroll through the list of outputs by using the
and keys. Shown in the top right corner of the display is an additional symbol:
– output is activated;
– output is deactivated.
Press the key to activate the output, or press the key to deactivate it.
Press the or key to switch over the keypad into the graphic mode. The
current status of all outputs available for control is presented in the upper line of display
by means of the and symbols. The key moves the cursor to the right, and the
key to the left. To change the status of a selected output, move the cursor over it
and press the or key. Press the or key for the keypad to return
to the text mode.
LED keypad
The lit LEDs indicate which outputs are active. Rapidly blinking LED indicates the
current place of cursor. The key moves the cursor to the right, and the key
– to the left. You can only move your cursor over the LEDs which correspond to the
outputs available for control. Press the key to activate the output with the number
corresponding to that of the LED, or press the key to deactivate it.
6.25 Tests
The 9. TESTS submenu is available to the users who have the TESTS right. Part of the
functions is only available in the LCD keypad.
6.25.1 Zone test
The function enables checking the system zones and detectors connected to them for proper
functioning.
1. Enter the user menu and press in turn the keys. 2 short beeps will
confirm entering the function, and the LED will go on.
2. Define the test duration. The test can last from 1 to 15 minutes. Enter two digits (e.g. for
the 5-minute duration, press in turn the and keys) and confirm using the
key.
3. In the LCD keypad, the system zones will be presented by means of the symbol, in
much the same way as when switching the keypad over into the mode of zone status
presentation (see: DISPLAY [LCD keypads]). In the LED keypad, the system zones will be
presented by blinking of corresponding LEDs.
4. Violate the selected zone (e.g. walking through the area supervised by the motion
detector or opening the window supervised by the magnetic contact). The zone violation
will be displayed on the LCD keypad by means of the symbol, and in the LED keypad, it
will be shown by lighting of the LED corresponding to the number of violated zone.
Information on the violation will be presented until the zone test is terminated.
Note: Zone violation during the test will not trigger the control panel reaction, as
preprogrammed for the zone.
5. The test will be terminated automatically after the defined time has elapsed. You can
terminate it earlier by pressing the key.
