www.schaerer.com Programming
26 / 56
Programming manual (Customer Program) / V03/05.2012
System conguration
► Press the [ Sys ] button (see Figure: "System conguration").
System conguration
System conguration - Parameters
1
If this eld is selected, the machine clock is automatically
updated with the time on the PC.
2
Brewing water temperature
Maximum setting = 95°C
3
Steam temperature
Must be set to 130°C.
4
Carbonate hardness of the water (0-4°,5-8°,9-12°,13-16°,
>16°kH).
See "Tables tab" on page 25.
5
Contrast setting for the display.
6
The counters can be protected against erasing using the
ve-digit PIN code "00002" ("Erase counters protected by
PIN code" must be activated on the "Options" tab). The PIN
code cannot be changed. In the service program, "2" is dis-
played instead of "00002".
PIN button key: 0 = hot water
1 = espresso 2 = coffee
5 = milk
3 = cappuccino 4 = latte macchiato
7
Water quantity remaining in the drinking water tank when
the "Fill up water tank" message is displayed.
4
5
1
8
Time setting in minutes after which the machine switches off
automatically.
9
[ EXIT ] button.
10
Machine language/display language
11
Enter the value of the grinding performance of the grinder.
The value is specied directly on the grinder. The value that
is NOT in the square brackets applies. To read off this value,
the machine housing must be opened.
12
By pressing the coffee bean, the value for the grinder em-
pty message is determined automatically. Important! There
must be no coffee beans in the bean hopper or in the grinder
as the measurement results will otherwise be incorrect.
2
3
6
7
8
Parameters tab
11
12
9
10
To be able to send the changed parameters to the machine, close the
"System configuration" menu using the "9" button (Exit). Then press
the "Send" button to transfer the data.
