www.schaerer.com Installation & commissioning
8 / 56
Programming manual (Customer Program) / V03/05.2012
Model Power requirements
Fuse protec-
tion
(in building)
Connec-
ting cable
conductor
cross-sec-
tion
Standard
220-240 V
AC
50/60 Hz 2000-2200 W
10-16 A 1.5 mm
2
England,
Ireland
13 A 1.5 mm
2
Australia, New Zeal-
and, China
15 A 1 mm
2
Denmark 10 A 1 mm
2
USA 120 V AC 50/60 Hz 1700 W 15 A AWG14
Japan 120 V 2 AC 50/60 Hz 2000 W 15 A 2.5 mm
2
The electrical power supply must be connected in accordance with the applicable regulations (VDE 0100)
and the regulations of the country of installation. Type of power cable at least H05 RN-F. The voltage spe-
cified on the serial plate must match the supply voltage at the installation location.
● The phase must be fused at the ampere value specied on the serial plate.
● It must be possible to disconnect the device from the mains power supply at all poles.
● Never operate a device with a damaged power cord. Have a defective power cord or plug replaced
immediately by a qualied service technician.
● Schaerer AG recommends against using an extension cable. If, despite this, an extension cable is
used (minimum cross-section: 1.5 mm2), observe the manufacturer data for the cable (operating
instructions) and the locally applicable regulations.
● The mains cables must be installed in such a way that they do not present a tripping hazard. Do
not pull the cords over corners or sharp edges, pinch them between objects or allow them to hang
loosely in a room. Do not position cables over hot objects and protect them from exposure to oil
and aggressive cleaning products.
● Never lift or pull the device by the power cable. Never pull the plug out of the socket by its cord.
Never touch the power cord or plug with wet hands! Never insert a wet plug into a power socket!
Serial plate
Machine-specific data (voltage/output) can be found on the serial plate. It is located on the right panel of
the grounds container shaft. The grounds container must be removed first.
Maximum voltage deviation: + 5%/- 10%
CAUTION!
Machine damage!
Type VAR Mod. Serial-No. Prod. Date
03.0430 001 PR 000100 02.2011
1/N/PE - 50/60 Hz 220 - 240 V max. 1.7 - 2.3 kW
permissible
max. pressure
1.6 M PA (16 bar)
produced by
wmf consumer
electric GmbH
Made in Germany
