1.1.1 Scotty 5000 Machine Specifications and Utility Requirements
Model Scotty 5000t
Speed
Up to 5000 tabs cut per hour
Up to 4200 tabs laminated and cut per hour
Sheet Size
355.6 mm x 342.9 mm (14” x 13--1/2”) maximum
127 mm x 111.1 mm (5” x 4--3/8”) minimum
Plastic Size
139.7 mm (5--1/2”) maximum
25.4 mm (1”) minimum
Tab Cut Size
127 mm (5”) maximum
12.7 mm (1/2”) minimum
Paper Load
Approximately 2000 sheets
Counter
1 -- 999999
Motor
1HorsePower
Electrical Requirements
30 Amps, 220VAC single phase, 50 or 60 Hz
Air Requirements
6 ScFm @ 80 P.S.I. (170LPM @ 5.3 bar)
Air Quality
Clean Dry Air filtered to 5 micron
Decibel Rating
94db
Dimensions
L--85” W--52” H--63” (L--2159mm W--1320.8mm H--1600.2mm)
Shipping Weight
2000 lbs (910 Kg)
Warranty
One year against defects in parts and workmanship
Note ! All Scott Machines require clean, dry air.
Optional air filters are available, contact your Scott representative for more details.
