HANDWHEEL SET-UPS FOR 12” SHEET WITH
1
/
2
” MARGINS
NOTE: SHADED AREAS ARE ACHIEVED BY TURNING THE STOCK UPSIDE DOWN. THE MIDDLE TAB IS JUST TO THE LEFT OF THE SHADED AREA.
TAB
B
A
N
K
TAB
S
I
Z
E
PLASTIC
PLASTIC POSITIONS & TAB POSITION
B
A
N
K
SIZE SIZE
HANDWHEEL DIMENSION
3 3.66 4.41
1 2 3
2.33 6.00 2.33
4 2.75 3.50
1 2 3 4
1.88 4.63 4.63 1.88
5 2.20 2.95
1 2 3 4 5
1.60 3.80 6.00 3.80 1.60
6 1.83 2.58
1 2 3 4 5 6
1.42 3.25 5.08 5.08 3.25 1.42
7 1.57 2.32
1 2 3 4 5 6 7
1.29 2.86 4.43 6.00 4.43 2.86 1.29
8 1.38 2.13
1 2 3 4 5 6 7 8
1.19 2.56 3.94 5.31 5.31 3.94 2.56 1.19
9 1.22 1.97
1 2 3 4 5 6 7 8 9
1.11 2.33 3.55 4.78 6.00 4.78 3.55 2.33 1.11
10 1.10 1.85
1 2 3 4 5 6 7 8 9 10
1.05 2.15 3.25 4.35 5.45 5.45 4.35 3.25 2.15 1.05
11 1.00 1.75
1 2 3 4 5 6 7 8 9 10 11
1.00 2.00 3.00 4.00 5.00 6.00 5.00 4.00 3.00 2.00 1.00
12 .92 1.67
1 2 3 4 5 6 7 8 9 10 11 12
.96 1.88 2.79 3.71 4.62 5.54 5.54 4.62 3.71 2.79 1.88 .96
13 .85 1.60
1 2 3 4 5 6 7 8 9 10 11 12 13
.92 1.77 2.61 3.46 4.31 5.15 6.00 5.15 4.31 3.46 2.61 1.77 .92
14 .79 1.54
1 2 3 4 5 6 7 8 9 10 11 12 13 14
.89 1.68 2.46 3.25 4.03 4.82 5.60 5.60 4.82 4.03 3.25 2.46 1.68 .89
15 .73 1.48
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
.87 1.60 2.33 3.07 3.80 4.53 5.26 6.00 5.26 4.53 3.80 3.07 2.33 1.60 .87
