1 Introduction and Safety
1--8
F--9999--8 Build 8 Issue 1
Fig. 1-7. Turn Machine Off Before Making
Adjustments
1.3.3 Main Power Switch
If machine is to be shut down for adjustments or
repairs, turn the power supply to the machine off.
VALVE
CONTROL
PLANT
AIR
SUPPLY
Fig. 1-8. Compressed Air Can Be Turned Off.
1.3.4 Compressed Air Valve
The compressed air line at the main AIR IN
features a ON/OFF valve for safety. The valve is
constructed to lockout down stream air pressure
when in the OFF position.
● The valve shuts off plant supplied compressed
air to the machine.
● Place the valve in the closed position when the
machine is not in use and prior to washing or
servicing the machine.
