SCOTT Scotty 5000 - METRIC HANDWHEEL SET-UPS for A4 (297 Mm X 210 Mm) TAB SIDE: 210 MM MARGIN: 0 MM

3-61
F--9999--8 Issue 1
METRIC HANDWHEEL SET-UPS FOR A4 (297mm x 210mm) TAB SIDE: 210 MM MARGIN: 0 MM
NOTE: SHADED AREAS ARE ACHIEVED BY TURNING THE STOCK UPSIDE DOWN. THE MIDDLE TAB IS JUST TO THE LEFT OF THE SHADED AREA.
END T AB POSITIONS ONL Y ALL OTHER TAB POSITIONS
TAB
BANK
T ABS TAB
SIZE
PLASTIC
LENGTH
PLASTIC
POSITION
TAB
POSITION
PLASTIC
LENGTH
POSITION
DIMENSION
2 -- 105.00 115.00 62.50 52.50 --
3 1&3 70.00 80.00 45.00 35.00 89.00 2
105.00
4 1&4 52.50 62.50 36.25 26.25 71.50 2 3
78.75 78.75
5 1&5 42.00 52.00 31.00 21.00 61.00 2 3 4
63.00 105.00 63.00
6 1&6 35.00 45.00 27.50 17.50 54.00 2 3 4 5
52.50 87.50 87.50 52.50
7 1&7 30.00 40.00 25.00 15.00 49.00 2 3 4 5 6
45.00 75.00 105.00 75.00 45.00
8 1&8 26.25 36.25 23.00 13.00 45.25 2 3 4 5 6 7
39.25 65.50 91.75 91.75 65.50 39.25
9 1&9 23.25 33.25 21.50 11.50 45.25 2 3 4 5 6 7 8
35.25 58.50 81.75 105.00 81.75 58.50 35.25
10 1&10 21.00 31.00 20.50 10.50 40.00 2 3 4 5 6 7 8 9
31.50 52.50 83.50 104.00 104.00 83.50 52.50 31.50
11 1&11 19.00 29.00 19.50 9.50 38.00 2 3 4 5 6 7 8 9 10
29.00 48.00 67.00 86.00 105.00 86.00 67.00 48.00 29.00
12 1&12 17.50 27.50 18.75 8.75 36.50 2 3 4 5 6 7 8 9 10 11
26.25 43.75 61.25 78.75 96.25 96.25 78.75 61.25 43.75 26.25
13 1&13 16.00 26.00 18.00 8.00 35.00 2 3 4 5 6 7 8 9 10 11 12
25.00 41.00 57.00 73.00 89.00 105.00 89.00 73.00 57.00 41.00 25.00
14 1&14 15.00 25.00 17.25 7.50 34.00 2 3 4 5 6 7 8 9 10 11 12 13
22.50 37.50 52.50 67.50 82.50 97.50 97.50 82.50 67.50 52.50 37.50 22.50
15 1&15 14.00 24.00 17.00 7.00 33.00 2 3 4 5 6 7 8 9 10 11 12 13 14
21.00 35.00 49.00 63.00 77.00 91.00 105.00 91.00 77.00 63.00 49.00 35.00 21.00
